Open Type Air Cooled
ZYC
PRODUCT ADVANTAGE
The Open Type Air Cooled Compressor Condensing Unit is engineered to deliver exceptional cooling efficiency, operational reliability, and installation flexibility for diverse commercial and industrial refrigeration projects. By integrating premium components with an accessible open-frame design, this unit provides a cost-effective and highly adaptable solution for modern refrigeration systems.
Designed to meet the rigorous demands of modern refrigeration, this condensing unit ensures rapid and consistent cooling performance across various environments.
Versatile Temperature Adaptability: Expertly engineered to support diverse thermal requirements, making it highly suitable for high-temperature processing workshops, medium-temperature fresh-keeping cold rooms, low-temperature cold storage, and blast freezers.
Advanced Heat Exchange: Equipped with high-performance fans that guarantee sufficient heat exchange, the system maximizes cooling output while maintaining stability during peak operational hours.
Eco-Friendly & Energy Saving: The unit is optimized to operate with environmentally friendly refrigerants, significantly reducing the carbon footprint. Its energy-saving design helps facility operators lower daily power consumption and achieve long-term operational cost reductions.
The structural design of the condensing unit prioritizes user convenience, significantly reducing the time and labor required for setup and routine maintenance.
Accessible Open Structure: The open-frame architecture ensures that all internal components are easily accessible. This layout facilitates convenient commissioning, quick inspections, and hassle-free maintenance for on-site engineers.
Separable Condenser Design: To accommodate projects where the machine platform is spatially limited or the completed set is too large for standard shipping containers, the air condenser can be installed separately and connected to its compressor unit directly at the site. This flexibility minimizes transportation challenges and adapts to complex installation environments.
Streamlined System Architecture: Compared to water-cooled and evaporative-cooled alternatives, the air-cooled system features fewer supplementary components. This streamlined approach makes the overall installation process simpler, faster, and more cost-efficient.
System stability is critical for refrigeration equipment. This unit is constructed using premium refrigeration parts that are assembled with meticulous care to optimize overall performance and longevity.
Enhanced Safety Components: The system features a large volume liquid receiver that comes equipped with a reliable safety valve, ensuring secure refrigerant management under fluctuating pressure conditions.
Convenient Monitoring: A strategically placed sight glass is easily viewable, allowing operators to monitor refrigerant levels and system health at a glance without interrupting operations.
Comprehensive Protection Mechanisms: To prevent mechanical damage and ensure continuous operation, the unit includes built-in high and low-pressure protection, as well as robust compressor overload protection.
Strict Quality Control: Before leaving the factory, every single unit undergoes rigorous pressure testing and leak detection. This stringent quality assurance process guarantees that the equipment arrives in perfect working condition, minimizing procurement risks.
Recognizing that every refrigeration project has unique specifications, this condensing unit offers outstanding adaptability and extensive customization options to align with specific engineering requirements.
Broad Compressor Compatibility: The system is designed to accommodate various types of refrigeration compressors, including highly efficient scroll, semi-hermetic reciprocating, or screw models, providing the exact cooling capacity required for your project.
Versatile Condenser Options: Multiple structural variations of the Open Type Air-Cooled Condenser are available, allowing for precise matching with site conditions.
Integrated Control Panel: An optional control panel can be mounted directly onto the unit. This panel includes all necessary electrical components and electrical control systems, simplifying on-site wiring and centralizing system management.
Fully Individualized Configurations: The equipment can be fully individualized by the customer. Buyers are free to change the brand and model of the compressor or other specific refrigeration parts, ensuring the final product perfectly matches their operational standards and budgetary considerations.
TECHNICAL PARAMETERS
DESIGN TEMPERATURE
Evaporation Temperature | Common Applications | |
|---|---|---|
High Temperature Series | -5℃ ~ +12℃ | Fruit and Vegetable Storage Food Processing |
Medium Temperature Series | -23℃ ~ 0℃ | Fruit and Vegetable Storage Chilled Food Storage |
Low Temperature Series | -46℃ ~ -13℃ | Meat and Seafood Storage Frozen Food Storage Ice Storage, Quick-freezing |
CONFIGURATION
Scroll Type | Semi-hermetic Reciprocating Type | Screw Type | |
|---|---|---|---|
Standard | scroll compressor | semi-hermetic reciprocating compressor differential oil pressure switch | screw compressor air/water cooled oil cooler |
open type air-cooled condenser liquid receiver with shut-off valve solenoid valve, filter drier and sight glass in liquid line vibration eliminator complete piping: discharge line, liquid line and suction line (insulated) hign and low pressure gauges hign and low pressure controller | |||
Optional | air cooled condenser fan speed control control panel with complete wiring (main switch, compressor contactor, etc.) check valve in liquid line oil seperator in discharge line gas seperator in suction line stainless steel ECO oil charge heaters for low ambient temperature | ||
PRODUCT USES
The Open Type Air Cooled Compressor Condensing Unit is engineered to deliver dependable refrigeration for demanding commercial and industrial environments. By providing consistent thermal control, this equipment helps facility managers and procurement teams meet strict storage regulations, reduce inventory loss, and maintain operational stability across diverse sectors.
Application Industry
Food Industry: Essential for processing plants, distribution hubs, and bulk storage facilities. The unit provides the reliable cooling necessary to preserve perishable goods, prevent spoilage, and ensure strict compliance with food safety and hygiene standards.
Medicine & Pharmaceuticals: Suitable for medical storage facilities requiring stringent temperature control. It supports the safe preservation of temperature-sensitive medications, vaccines, and critical biological samples, helping healthcare supply chains mitigate the risk of product degradation.
Chemicals: Designed to handle the rigorous demands of chemical manufacturing and storage. It provides stable process cooling for volatile substances and specialized compounds, ensuring that sensitive chemical reactions and storage environments remain within safe thermal limits.
Logistics & Warehousing: A vital component for large-scale distribution centers and third-party logistics providers. The equipment supports extensive cold storage networks, enabling operators to manage diverse, temperature-dependent inventory efficiently across the entire supply chain.
Application Scenario
Walk-in Freezers: Delivers continuous, heavy-duty freezing capabilities for commercial kitchens, supermarkets, and bulk storage areas. It helps businesses maintain deep-freeze conditions reliably, protecting large volumes of frozen inventory from temperature fluctuations.
Cold Rooms: Ideal for medium to large-scale cold storage rooms. The unit ensures uniform temperature distribution, creating a stable environment that protects fruits, vegetables, dairy, and other sensitive goods during short- or long-term holding periods.
Cold Chain: Serves as a dependable cooling node within broader cold chain networks. By maintaining strict temperature parameters at transfer points and holding facilities, it safeguards product integrity from the initial production phase through to final delivery.
Process Cooling: Integrates effectively into industrial manufacturing lines that require continuous heat removal. It supports machinery cooling and production processes, helping plant operators prevent equipment overheating and maintain consistent production cycles.
Retail: Supports the back-end storage and large display refrigeration needs of supermarkets and grocery stores. It balances efficient cooling performance with the rigorous operational demands of fast-paced retail settings, ensuring products remain safe for consumers.
By aligning with these specific industries and usage scenarios, the unit offers a practical, adaptable refrigeration solution. It is designed to help purchasing teams and project engineers secure reliable cooling infrastructure that supports long-term facility operations and minimizes the risk of costly downtime.
